Milwaukee® 2217-20 Digital Multimeter, 600 VDC/VAC, 10 A, 40 MOhm Measuring, 6 mV to 600 VAC, 600 mV to 600 VDC, 10 A, 600 Ohm to 40 MOhm, High Contrast White on Black Display
multimeter dgtl 10a 600 ohm to 40 mohm
Stellar Part #MILWA 2217-20
MFG Part #2217-20
MFG Name:Milwaukee Tool
Product Description:
Milwaukee® Digital Multimeter, 600 VDC/VAC, 10 A, 40 MOhm Measuring, 6 mV to 600 VAC, 600 mV to 600 VDC, 10 A, 10 Hz to 50 kHz Frequency, 600 Ohm to 40 MOhm Resistance, Safety Rating: CAT III 600 VAC, 1000 uF Capacitance, +/-0.5% + 2 Digits Accuracy, High Contrast White on Black Display, AA Alkaline Battery, 6-1/2 in L Dimensions, -40 to 752 deg F
Login For Price
- Item Features
- Technical Specifications
- Resources
- True-RMS for accurate measurement in all applications
- Rugged overmolding increases durability and user grip
- Low-Z measurement to eliminate ghost voltage
- High contrast white on black display with backlight for easy reading
- Rugged 26 ga galvanized steel construction housing
- White on black display with backlight for easy reading
- True-RMS for accurate measurement in all applications
- Rugged overmolding increases durability and user grip
- Low-Z measurement to eliminate ghost voltage
- High contrast white on black display with backlight for easy reading
- Rugged 26 ga galvanized steel construction housing
- White on black display with backlight for easy reading
- Accuracy:+/-0.5% + 2 DigitsAmperage Rating:10 ABattery Type:AA AlkalineCapacitance:1000 uFDimensions:6-1/2 in LDisplay Type:High Contrast White on BlackFrequency Rating:10 Hz to 50 kHzMeasuring Range:600 VDC/VAC, 10 A, 40 MOhmResistance:600 Ohm to 40 MOhmSafety Rating:Cat III 600 VACTemperature Rating:-40 to 752 deg C, -40 to 752 deg FVoltage Rating:6 mV to 600 VAC, 600 mV to 600 VDC
